DOOSAN XHP1250CMH-2100 DRILL MODULE
Features
Title | DOOSAN XHP1250CMH-2100 DRILL MODULE |
Type | Compressors |
Sub Type | Compressor Attachments |
Make | DOOSAN |
Model | XHP1250CMH-2100 DRILL MODULE |
Sale Price | POA |
Listing Type | New |
Stock Number | S377 |
RefCode | TA585700 |
Description
XHP1250CMH-2100 Drill Module
Model: XHP1250CMH-2100
Free Air Delivery: 35.4 m³/min (1250 cfm)
Pressure: 24.1 bar (350 psi)
Doosan offers the broadest range of compressor modules in the industry. All models have proven reliable airends and sub-systems. All models are supplied with a remote oil separator tank as standard. We have got you covered with dedicated engineering support for installation and worldwide service and support.
XHP1250CMH-2100 Drill Module
Contact Clark Equipment today for the best price / finance deal on this product!
Model: XHP1250CMH-2100
Free Air Delivery: 35.4 m³/min (1250 cfm)
Pressure: 24.1 bar (350 psi)
Doosan offers the broadest range of compressor modules in the industry. All models have proven reliable airends and sub-systems. All models are supplied with a remote oil separator tank as standard. We have got you covered with dedicated engineering support for installation and worldwide service and support.
XHP1250CMH-2100 Drill Module
- Choice of shaft drive (CM or CMH), direct engine coupling (CMH only) or hydraulic drive of compressor (CMH only)
- Onboard air-cooled compressor oil cooler, fan shaft driven (CM) or optional hydraulic drive (CMH)
- Pusher fan with straight through cooling flow keeps package interior temperature near ambient
- Heavy-gauge sheet metal housing
- Heavy-duty frame with integral fork lift tubes
- Dual two-stage air cleaners with safety elements
- Available hydraulic drive adapter plate for mounting motor (CMH only)
- Flexible drive coupling included with hydraulic drive adapter plate
- Removable roof panel (CMH only) and side- or rear-access panels
- Mounting provisions on sides and bottom of frame
- Includes pressure regulation, separator scavenge and automatic blowdown systems, 165 PSIG min. pressure valve
- Air filters protected inside the package from rain and damage
- Roof-mounted automatic shutters protect oil cooler from environment and debris (CM only)
- Integral lifting hard points at top corners of housing
